Tensile membrane structure supported by two main columns, four secondary columns and two arched beams.
TMS059 | Membrane Structure with Arched Beams
| Block parameters editable dynamically | |
| Number of Nodes | 20 |
| Number of Lines | 22 |
| Number of Members | 22 |
| Number of Surfaces | 3 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 4.705 tons |
| Dimensions (Metric) | 22,000 x 4,500 x 22,000 m |
| Dimensions (Imperial) | 72.18 x 14.76 x 72.18 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
