A truss structure consists of three rods - one steel and two copper joined by a rigid member. The structure is loaded by a concentrated force and by a temperature difference. While neglecting self‑weight, determine the total deflection of the structure.
Submodels
Model Used in
Verification Example 000076 | 3
| Number of Nodes | 18 |
| Number of Lines | 19 |
| Number of Members | 4 |
| Number of Surfaces | 3 |
| Number of Load Cases | 1 |
| Total Weight | 0.001 tons |
| Dimensions (Metric) | 1.070 x 0.070 x 0.535 m |
| Dimensions (Imperial) | 3.51 x 0.23 x 1.76 feet |
| Program Version | 5.10.01 |
