Question:
After converting a CAD/BIM object to a member, the CAD/BIM object is missing.
Was it deleted during the conversion?
Answer:
When converting to a member, the CAD/BIM objects are not deleted, but only hidden. In the Project Navigator, you can display the automatically hidden objects again. The short video shows you how it works.
