Building in Nashville
No Download Possible
Customer Project / View Only
Number of Nodes | 9 |
Number of Lines | 12 |
Number of Surfaces | 6 |
Number of Load Cases | 3 |
Dimensions (Metric) | 441.229 x 85.505 x 75.000 m |
Dimensions (Imperial) | 1447.6 x 280.53 x 246.06 feet |
Program Version | 5.24.00 |
