Prestressed Concrete Beam with Integrated Reinforcing Tendons
A reinforced concrete continuous beam featuring integrated tendons used for prestressing reinforcement to enhance structural performance.
The image illustrates a reinforced concrete continuous beam equipped with integrated tendons designed for prestressing reinforcement. These structural elements enhance the beam's load-bearing capacity and performance.
3D 模型
详细说明
| 节点数目： | 13 |
| 线的数目 | 9 |
| 杆件数目： | 9 |
| 面的数目： | 0 |
| 实体数目 | 0 |
| 荷载工况数目 | 3 |
| 荷载组合数目 | 8 |
| 结果组合数目 | 0 |
| 总重量 | 0,112 t |
| 翘曲区域尺寸 | 45.000 x 0.846 x 0.000 m |
