Individual Definition of Effective Flange Widths of Ribs by Segment

Definition of different flange widths of T-beams for integration in the design of concrete ribs.

In the image, the definition of the effective width of T-beams within a single member is displayed. The different flange widths can be varied segment by segment, and the transition between them can be either stepped or linear. When performing design of reinforced concrete ribs, the defined surface reinforcement is integrated as flange reinforcement.
